Simultaneous detection of RF transmitted signals over a wide spectrum of frequencies spanning from 3 MHz to over 5 GHz, including cellular phones and wireless phones, FM, TV and short wave broadcasts, computer wireless devices, wireless security systems, microwave ovens, ham radio, police and service bands, and transmitting surveillance and spying devices such as hidden cameras, transmitting bugs and covert video or data transmissions.
Very high sensitivity with the ability to detect signals from wireless devices, cellular phones and covert “bugs” at more than 50+ feet, transmissions from “sealed” microwave ovens at 40+ feet, from walkie-talkies at 100+ feet, and from amateur radio transceivers at hundreds of feet.
Detection and differentiation between analog RF signals and digital transmissions. Enhances the detection of cell phones, wireless phones and computer wireless signals.
Wide dynamic range display in the LOG (logarithmic) mode covering a 1000 to 1 input signal range, as well as a highly sensitive LINEAR mode where only the weak signals are examined. A MID mode is used for detection and measurement of intermediately strong RF signals
Input signal strengths in the LOG mode, MID mode, and LINEAR mode are adjustable by using a sensitivity controller.
RF field strengths displayed on both an analog meter and colored Light-Emitting Diode (LED) displays. The LED display produces better readability from a distance and in dim light such as nighttime.
A silent vibrator mode allowing the instrument to be used to detect radiated RF signals (as from a hidden camera or body “bugs”) without being observed. The silent vibrator mode is independently switched ON or OFF.
Fixed internal antennas which do not require any adjustments and give repeatable signal strength readings.
SPECIFICATIONS
Sensitivity
70 uV (microvolts)
Bandwidth < 3 MHz to > 5 GHz
useable frequency range
Sensitivity Controller 20 dB, (10 to 1) signal
control range
Detection Modes LINEAR for far-field
detection of the weakest signals 10 dB
dynamic signal range
LOG for near-field
localization without overloading 60 dB
dynamic range
MID for intermediate
detection and localization 25 dB
dynamic signal range
Analog Mode For
detecting and measuring continuously transmitted signals
Digital Mode For detecting,
identifying and measuring digitally pulsed signals
Silent Vibrator Intensity modulated,
switch enabled vibrator for mid to high signal levels
Analog Meter Display Visual indication of changes
and levels of RF signals
LED Display Gradually dimming and
enhanced LED lighting depending upon detected signal
strength
·
Green LED - Maximum at low signal levels -
dims as signal strength increases
·
Red LED – Unlit at low signal levels –
gradually changes from dim to bright as signal level gets stronger
·
Simultaneous lit Green and Red LEDs due to
Digital Signals with rapid on/off switching
Weight
Less than 5.0 oz. (150 gm) with batteries installed
Dimensions 2.1 in. wide x 5.0
in. high x 1.25 in. thick (5.6 cm
wide x 13 cm high x 3.1 cm thick)
Battery Life Approximately 80
hours (2 Alkaline AA cells)
