INMARSAT Receive-Only Antenna System
NEW UNIT IN STOCK
This powerful antenna system utilizes a high gain, light weight,
loop Yagi to pick up weak INMARSAT communications
satellite signals which are boosted by a custom made, low noise,
high-gain preamplifier mounted at the antenna for lowest loss.
The FM signals are then delivered by coax to your
wide-frequency-coverage scanner or receiver.
Operating power for the preamp is inserted into the coax by an
indoor bias supply.
SPECIFICATIONS:
Antenna:
Construction: Aluminum and stainless steel; 1-1/2" stainless steel U-bolt mount
Frequency Range : 1.52-1.56 GHz
Number of elements: 45
Boom Length: 120 inches
Boom diameter: 0.75 inches
Mast diameter: 1-1/2 inches
Weight: 3 lbs
Connector: N female
Gain: 20.0 dBi
3 dB Beamwidth (E Plane):16 degrees
F/B ratio: 20 dB or greater
LNA:
Frequency range: 1500-1650 MHz
Dynamic range: +35 dBm
Noise figure: 0.7 dB
Gain: 25 dB or greater
Power required: 13.6 VDC @ 150 mA nom. from power inserter
Housing: Weatherproof
Connector: N
Power inserter
RF connectors: Type N, male output and female input
DC connection: Power jack for 13.6 VDC (nom.) @ 150 mA
AC adaptor:
120 VAC input / 13.6 VDC @ 150 mA output
Coaxial cable:
50' low-loss RG-6/U with choice of N or BNC connector
FULL MFG WARRANTY
All accessories, missing whip antenna and interior packing.
http://www.grove-ent.com/bct8techspecs.htm
ALL ACCESSORIES
MISSING BELT CLIP SCREWS
FULL MFG WARRANTY
ALL FUNCTIONS WORK
SMALL AMOUNT OF RUST ON TOP OF UNIT BUT IN GOOD CONDITION.
MAXIMUM VOLUME IS LOWER THAN NORMAL
AC POWER, MANUAL, LONGWIRE ANTENNA
FULL WARRANTY
SLIGHT MAR ON LCD
ALL ACCESSORIES
DISPLAY BOX.
S#328Z64004281
ALL ACCESSORIES
DISPLAY BOX
S#EFR500080005955
BATTERY PACK & MANUAL
White American Red Cross Unit
BOX AND STYROFOAM PACKING TORN
FULL MFG WARRANTY
http://www.grove-ent.com/SCN51.html
The Grace GDI-IR3020 digital WiFi radio is a basic model with nice features including an iPod dock. It is modernistically styled and includes a full-function remote control. The easy-to-read, four-line LCD announces time as well as station information. A single knob makes selections quick and easy.
The radio links wirelessly to your WiFi hub or may be wired directly via its modular LAN connector. A conventional 1/8” (3.5 mm) stereo headphone jack is on the rear panel alongside the left and right channel RCA jacks which can route the radio’s audio to your existing home entertainment system.
The two internal 2-1/2” speakers provide bright, clear sound, and the intuitive instructions are easy to follow, with a well-indexed table of contents.
FULL MFG WARRANTY
RET'D FROM CUSTOMER WITH TORN BOX
http://www.grove-ent.com/bc246t.html
Klingenfuss 2008 Super Frequency List
2008 Super Frequency List on CD
Worldwide HF Communication TodayThe only CD
that includes all shortwave broadcast stations worldwide
PLUS all HF utility stations from 0 to 30 MHz -
PLUS hundreds of digital data decoder screenshots!
Uniden BP-200 Battery Pack
Uniden BP-200, 600mAh 7.2 Volts Ni-Cad battery pack, for use with the BC-200XLT
ACL BP-1200 Ni-Mh Battery
ACL 1200B Ni-Mh Battery Pack, lasts 50% longer than the stock battery pack. For use with SC-150Y/B, SC-180, SC-200, BC-220, BC-235XLT, BC-245XLT.
Uniden UA-502A Coiled DC Power Cord
UA502A - Coiled DC Power Cord for use with the
Uniden BC-3000XLT, BC-245XLT, BC-250D, & BC-296D
Alinco ESC-29 Soft Case
Softcase for use with EBP-37N. Alinco DJ-X10T/K or the DJ-X2000T/K
Alinco EDC-36 DC Cable w/ Filter
EDC-36 Mobile cigarette lighter adapter with active noise filter for use with the Alinco DJ-X10T/K and the DJ-X2000T/K.
ICOM OPC-478 Computer Interface Cable
Provides quick and easy programming of memory channels,
memory names and set mode contents via a compatible PC. For use with the
ICOM R-10 & the ICOM R-2
ICOM LC-151 Leather Case
CLOSEOUT ITEM
ICOM LC-151 leather carrying case for the Icom R-3. Helps protect the receiver from scratches, etc.
ICOM R-3 Desktop Charger
ICOM R-3 Desktop Charger for rapid charging of battery pack, BP-206. An AC adapter, is supplied with the charger. Charging time approx.2.5 hours.
ICOM BP-206 Battery Pack
Li-Ion battery pack 3.7 Volt 1650 mAh for Icom R-3.
ICOM R-3 PC Software
CLOSEOUT ITEM
For use with the ICOM R-3 and the OPC 478 computer interface cable. Allows quick and simple setting of receiving frequencies, memory names, etc., from a PC.
SYSTEM REQUIREMENTS
- Pentium 100 MHz or faster
- Windows 95/98
- 16 MB RAM
- 640 x 480 minimum pixel display
- RS232 Serial Port
WR USB Adaptor for MAC
The Keyspan USB Adapter (USA-19 Model) provides a quick and easy way to connect the WR-1550e receiver to a Macintosh computer.
The Keyspan USB Adapter is supported under Mac OS, and requires only a simple "plug and play" installation. The Adapter supports up to 57.6 Kbps data transfer rate, which meets the interfacing requirements of a WR-1550e receiver.
The Adapter features a USB cable which plugs to the computer, and a DB-9 serial connector which is compatible with the WR-1550e receiver serial cable. A software driver is supplied on a CD ROM.
Native MacOS software for such arrangement (MacRadio) is available for free download.
WR to MAC Serial Interface Cable
The WR-MAC-SC-01 Serial Cable is designed to provide a reliable connection between the WR-1550e receiver and a Macintosh computer with a standard serial port.
The Cable has a Macintosh standard
(Mini-DIN) connector which plugs to the computer, and a DB-9 serial
connector which is compatible with the WR-1550e receiver serial port. No
special software driver is necessary. The cable also contains two ferrite
EMI suppressors which serve to reduce electromagnetic interference and
maximize the performance of the receiver.
Native MacOS software for such arrangement (MacRadio) is available for free download
